Volume pricing
- 1+ pcs$186.44
- 10+ pcs$175.88
- 100+ pcs$165.93
- 500+ pcs$156.53
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- RoHS Durumu
- ROHS3 Compliant
- Power Max
- 1550W
- Vceon Max Vge Ic
- 3V @ 15V, 200A
- Case Connection
- ISOLATED
- Çalışma Sıcaklığı
- 150°C TJ
- Ntc Thermistor
- No
- Input
- Standard
- Yayın Yılı
- 1998
- Currentcollector Ic Max
- 300A
- Terminal Formu
- UNSPECIFIED
- Kılıf / Paket
- Module
- ECCN Kodu
- EAR99
- Kurşunsuz Kodu
- yes
- Yüzey Montaj
- NO
- Number Of Elements
- 1
- Configuration
- Single Switch
- Jesd30 Code
- R-XUFM-X5
- Pin Sayısı
- 5
- Terminal Pozisyonu
- UPPER
- Input Capacitance Cies Vce
- 13nF @ 25V
- Voltage Collector Emitter Breakdown Max
- 1200V
- Montaj Tipi
- Chassis Mount
- Parça Durumu
- Not For New Designs
- Terminal Sayısı
- 5
- Polaritychannel Type
- N-CHANNEL
- Current Collector Cutoff Max
- 4mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Turn On Time
- 210 ns
- Turn Off Timenom Toff
- 630 ns
- Transistor Element Material
- SILICON
