Specifications
- Çalışma Sıcaklığı
- -40°C~120°C
- Number Of Poles
- 1
- Montaj
- PCB, Panel, Through Hole
- Actuator Type
- Lever, Straight
- Voltage Rated Dc
- 48V
- Uzunluk
- 12.7mm
- Terminal Stili
- PC Pin
- Orientation
- Straight
- Contact Current Rating
- 3A
- Actuator Length
- 130mm
- Contact Currentacmax
- 3A
- Additional Feature
- MICRO SWITCH
- Akım Değeri
- 3A
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Fabrika Tedarik Süresi
- 11 Weeks
- Depth
- 5.8mm
- Reach Svhc
- Unknown
- Pozisyon Sayısı
- 2
- Mechanical Life
- 1,000,000 Cycles
- JESD-609 Kodu
- e3
- Release Force
- 8.000gf
- Max Current Rating
- 3A
- Overtravel
- 0.025 (0.6mm)
- Terminal Kaplaması
- Matte Tin (Sn)
- Housing Material
- Nylon
- Parça Durumu
- Active
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 48gf
- Pretravel
- 0.134 (3.4mm)
- Contact Materials
- Silver
- Circuit
- SPDT
- RoHS Durumu
- RoHS Compliant
- Ambalaj
- Bulk
- Yayın Yılı
- 2008
- Body Height
- 6.5mm
- HTS Kodu
- 8536.50.70.00
- Switch Function
- On-Mom
- Onay Kuruluşu
- CE, CSA, UL
