Specifications
- Circuit
- SPDT
- Actuator Length
- 118mm
- Terminal Kaplaması
- Matte Tin (Sn)
- Housing Material
- Nylon
- Electricallife
- 1,000,000 Cycles
- Kurşunsuz Kodu
- yes
- Max Voltage Rating Dc
- 48V
- RoHS Durumu
- RoHS Compliant
- Current Rating Amps
- 100mA DC
- Reach Svhc
- Unknown
- Montaj Tipi
- Chassis Mount
- Depth
- 5.8mm
- Operating Force
- 55gf
- Contact Materials
- Silver
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Body Length Or Diameter
- 12.7mm
- Contact Plating
- Gold
- Mechanical Life
- 1,000,000 Cycles
- Ambalaj
- Bulk
- Pretravel
- 0.150 (3.8mm)
- Contact Current Rating
- 200mA
- Seri
- ZX
- Çalışma Sıcaklığı
- -40°C~120°C
- Terminal Stili
- Solder Lug
- HTS Kodu
- 8536.50.70.00
- Overtravel
- 0.025 (0.6mm)
- Parça Durumu
- Active
- Voltage Rated Ac
- 125V
- Switch Function
- On-Mom
- Fabrika Tedarik Süresi
- 5 Weeks
- Contact Currentdcmax
- 0.1A
- ECCN Kodu
- EAR99
- Differential Travel
- 0.050 (1.3mm)
- JESD-609 Kodu
- e3
- Akım Değeri
- 100mA
- Yayın Yılı
- 2014
- Voltage Rated Dc
- 48V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Orientation
- Straight
- Montaj
- Chassis Mount, Screw, Solder, Through Hole
