Volume pricing
- 1+ pcs$10.03
- 10+ pcs$9.46
- 100+ pcs$8.92
- 500+ pcs$8.42
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pretravel
- 0.047 (1.2mm)
- Montaj
- Chassis Mount, Screw, Solder, Through Hole
- Release Force
- 50gf
- Ingress Protection
- IP00
- Çalışma Sıcaklığı
- -40°C~120°C
- Contact Materials
- Silver
- Terminal Stili
- Solder Lug
- Circuit
- SPDT
- Body Height
- 9mm
- Switch Function
- On-Mom
- Montaj Tipi
- Chassis Mount
- Electricallife
- 10,000 Cycles
- Yayın Yılı
- 2010
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Round (Pin Plunger)
- Operating Force
- 203gf
- Additional Feature
- MICRO SWITCH
- Contact Currentacmax
- 5A
- Mechanical Life
- 2,000,000 Cycles
- Current Rating Amps
- 5A AC
- Fabrika Tedarik Süresi
- 11 Weeks
- Depth
- 6.4mm
- Kurşunsuz
- Lead Free
- Max Voltage Rating Ac
- 250V
- Parça Durumu
- Active
- Ambalaj
- Bulk
- ECCN Kodu
- EAR99
- Uzunluk
- 19.8mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Akım Değeri
- 5A
- Operating Position
- 0.330 (8.4mm)
- Differential Travel
- 0.008 (0.2mm)
- Terminal Kaplaması
- Matte Tin (Sn)
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Pozisyon Sayısı
- 2
- Kurşunsuz Kodu
- yes
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Ac
- 125V
- Housing Material
- PBT
