Volume pricing
- 1+ pcs$1.04
- 10+ pcs$0.99
- 100+ pcs$0.93
- 500+ pcs$0.88
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Yayın Yılı
- 2002
- Ambalaj
- Bulk
- REACH Uyumluluk Kodu
- unknown
- Uzunluk
- 19.81mm
- Contact Materials
- Cadmium, Silver
- Differential Travel
- 0.032 (0.81mm)
- Contact Currentacmax
- 5A
- Fabrika Tedarik Süresi
- 11 Weeks
- Terminal Kaplaması
- Matte Tin (Sn)
- Housing Material
- Nylon
- Seri
- ZV
- Max Voltage Rating Ac
- 250V
- Actuator Length
- 174mm
- Actuator Type
- Lever, Straight
- Montaj
- Chassis Mount, Screw, Solder, Through Hole
- Number Of Poles
- 1
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Onay Kuruluşu
- CE, UL
- Switch Function
- On-Mom
- Voltage Rated Dc
- 125V
- Operating Position
- 0.465 (11.8mm)
- Parça Durumu
- Active
- Mechanical Life
- 10,000,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Depth
- 6.4mm
- Kurşunsuz Kodu
- yes
- Pozisyon Sayısı
- 2
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e3
- Release Force
- 10gf
- Akım Değeri
- 6A
- Orientation
- Straight
- Voltage Rated Ac
- 250V
- ECCN Kodu
- EAR99
- Max Current Rating
- 6A
- HTS Kodu
- 8536.50.70.00
- Additional Feature
- MICRO SWITCH
- Operating Force
- 50gf
- Overtravel
- 0.035 (0.9mm)
- Çalışma Sıcaklığı
- -40°C~120°C
