Specifications
- Overtravel
- 0.015 (0.4mm)
- Housing Material
- Nylon
- Çalışma Sıcaklığı
- -40°C~120°C
- Seri
- ZV
- Terminal Stili
- Solder Lug
- Max Voltage Rating Ac
- 250V
- Actuator Type
- Round (Pin Plunger)
- Montaj
- Chassis Mount, Screw, Solder, Through Hole
- Pretravel
- 0.043 (1.1mm)
- Body Height
- 9.9mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Kurşunsuz
- Lead Free
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Terminal
- Solder
- Circuit
- SPDT
- Current Rating Amps
- 6A AC
- Voltage Rated Dc
- 125V
- Operating Position
- 0.449 (11.4mm)
- Mechanical Life
- 10,000,000 Cycles
- Contact Ac Max Rating R Load
- 5A@250VAC
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Depth
- 6.4mm
- Electricallife
- 10,000 Cycles
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e3
- Yayın Yılı
- 2009
- Release Force
- 35gf
- Ambalaj
- Bulk
- Akım Değeri
- 6A
- REACH Uyumluluk Kodu
- unknown
- Orientation
- Straight
- Uzunluk
- 19.8mm
- Voltage Rated Ac
- 125V
- Contact Materials
- Cadmium, Silver
- ECCN Kodu
- EAR99
- HTS Kodu
- 8536.50.70.00
- Max Current Rating
- 6A
