Volume pricing
- 1+ pcs$2.03
- 10+ pcs$1.91
- 100+ pcs$1.81
- 500+ pcs$1.70
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Operating Force
- 35gf
- RoHS Durumu
- RoHS Compliant
- Actuator Length
- 166mm
- Electricallife
- 6,000 Cycles
- Body Breadth
- 6.4 mm
- Contact Materials
- Silver
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 125V
- Pretravel
- 0.150 (3.8mm)
- Kılıf / Paket
- 125
- Circuit
- SPDT
- Operating Position
- 0.689 (17.5mm)
- Differential Travel
- 0.030 (0.76mm)
- Orientation
- Straight
- Overtravel
- 0.030 (0.76mm)
- Additional Feature
- MICRO SWITCH
- Current Rating Amps
- 5A AC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Terminal Stili
- Quick Connect - 0.110 (2.8mm)
- Montaj
- Chassis Mount, Panel, Screw
- Voltage Rated Dc
- 30V
- Actuator Type
- Lever, Roller
- Mechanical Life
- 10,000,000 Cycles
- Switch Function
- On-Mom
- Pozisyon Sayısı
- 2
- Çalışma Sıcaklığı
- -40°C~120°C
- ECCN Kodu
- EAR99
- Terminal
- Solder
- Terminal Kaplaması
- Matte Tin (Sn)
- Fabrika Tedarik Süresi
- 8 Weeks
- JESD-609 Kodu
- e3
- Akım Değeri
- 5A
- Contact Currentacmax
- 5A
- Parça Durumu
- Active
- Housing Material
- Nylon
- Body Height
- 10.6mm
- Body Length Or Diameter
- 19.8mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Ambalaj
- Bulk
- Max Voltage Rating Ac
- 250V
