Volume pricing
- 1+ pcs$1.45
- 10+ pcs$1.37
- 100+ pcs$1.29
- 500+ pcs$1.22
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Electricallife
- 10,000 Cycles
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 19.8mm
- Operating Force
- 60gf
- Kurşunsuz Kodu
- yes
- Pretravel
- 0.043 (1.1mm)
- Differential Travel
- 0.008 (0.2mm)
- Kılıf / Paket
- 125
- Additional Feature
- MICRO SWITCH
- Current Rating Amps
- 100mA AC/DC
- Orientation
- Straight
- Voltage Rated Dc
- 30V
- Montaj
- Chassis Mount, Screw, Solder, Through Hole
- Reach Svhc
- Unknown
- Terminal Stili
- Solder Lug
- Mechanical Life
- 10,000,000 Cycles
- Actuator Type
- Round (Pin Plunger)
- Pozisyon Sayısı
- 2
- Fabrika Tedarik Süresi
- 12 Weeks
- Terminal
- Solder
- ECCN Kodu
- EAR99
- Contact Currentacmax
- 0.1A
- Akım Değeri
- 100mA
- JESD-609 Kodu
- e3
- Body Height
- 10.6mm
- Seri
- ZM
- Yayın Yılı
- 2011
- Depth
- 6.4mm
- Contact Current Rating
- 100mA
- Contact Materials
- Gold, Silver
- Voltage Rated Ac
- 125V
- Operating Position
- 0.449 (11.4mm)
- Actuator Material
- Polyamide
- Circuit
- SPDT
- Overtravel
- 0.015 (0.4mm)
- Contact Plating
- Gold
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -40°C~120°C
- Terminal Kaplaması
- Matte Tin (Sn)
