Specifications
- Operating Force
- 130gf
- Voltage Rated Ac
- 125V
- Reach Svhc
- Unknown
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Current Rating Amps
- 3A AC/DC
- RoHS Durumu
- RoHS Compliant
- Housing Material
- PBT
- Switch Function
- On-Mom
- Differential Travel
- 0.012 (0.3mm)
- Contact Materials
- Silver
- Body Height
- 9.05mm
- Uzunluk
- 14.7mm
- Montaj
- Through Hole
- HTS Kodu
- 8536.50.70.00
- Depth
- 5.4mm
- Operating Position
- 0.120 (3.05mm)
- Actuator Type
- Round (Pin Plunger)
- Max Current Rating
- 3A
- Terminal Stili
- PC Pin
- Release Force
- 13gf
- Overtravel
- 0.030 (0.76mm)
- Max Voltage Rating Ac
- 125V
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Mechanical Life
- 500,000 Cycles
- Pretravel
- 0.030 (0.8mm)
- Circuit
- SPDT
- Contact Currentdcmax
- 3A
- Seri
- ZD
- Contact Currentacmax
- 3A
- Contact Dc Max Rating R Load
- 3A@12VDC
- Terminal
- PCB
- Orientation
- Straight
- Akım Değeri
- 3A
- Additional Feature
- MICRO SWITCH
- Voltage Rated Dc
- 12V
- Çalışma Sıcaklığı
- -40°C~120°C
- Yayın Yılı
- 2010
- Contact Current Rating
- 3A
- Parça Durumu
- Active
- Ambalaj
- Bulk
