Specifications
- Overtravel
- 0.005 (0.13mm)
- Body Length Or Diameter
- 49.28mm
- Yayın Yılı
- 2001
- Kurşunsuz Kodu
- yes
- Seri
- YZ
- Orientation
- Straight
- Circuit
- SPST-NO
- ECCN Kodu
- EAR99
- Özellikler
- Reset Plunger on Bottom
- Throw Configuration
- SPST
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Round (Pin Plunger)
- Contact Dc Max Rating R Load
- .5A@125VDC
- Actuator Travel
- 0.44 mm
- Body Breadth
- 17.45 mm
- Switch Function
- Off-On
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Reach Svhc
- No SVHC
- Operating Position
- 0.625 (15.9mm)
- Montaj Tipi
- Chassis Mount
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Quick Connect
- HTS Kodu
- 8536.50.70.00
- Contact Currentdcmax
- 0.5A
- Body Height
- 21.34mm
- Voltage Rated Ac
- 125V
- Akım Değeri
- 15A
- Pretravel
- 0.012 (0.3mm)
- Operating Force
- 198 ~ 255gf
- Contact Materials
- Silver
- Max Voltage Rating Dc
- 250V
- Pretravelmax
- 0.31 mm
- Max Voltage Rating Ac
- 480V
- Voltage Rated Dc
- 125V
- Mechanical Life
- 20,000,000 Cycles
- Montaj
- Chassis Mount, Panel, Screw
- Housing Material
- Phenolic
- Fabrika Tedarik Süresi
- 10 Weeks
