Volume pricing
- 1+ pcs$7.61
- 10+ pcs$7.18
- 100+ pcs$6.77
- 500+ pcs$6.39
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Release Force
- 283gf
- Seri
- YE
- Terminal
- Screw
- Housing Material
- Phenolic
- Actuator Travel
- 3.66 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Throw Configuration
- SPDT, SPST
- Contact Ac Max Rating R Load
- 25A@250VAC
- Kurşunsuz Kodu
- yes
- Çalışma Sıcaklığı
- -55°C~85°C
- Montaj Tipi
- Chassis Mount
- Contact Materials
- Cadmium, Silver
- Differential Travel
- 0.007 (0.18mm)
- Circuit
- SPST-NO
- Terminal Kaplaması
- Matte Tin (Sn)
- Operating Force
- 397 ~ 624gf
- Voltage Rated Ac
- 125V
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- JESD-609 Kodu
- e3
- Body Length Or Diameter
- 49.28mm
- Overtravel
- 0.094 (2.4mm)
- Parça Durumu
- Active
- Pretravelmax
- 1.27 mm
- Pretravel
- 0.050 (1.27mm)
- Montaj
- Chassis Mount, Panel, Screw
- Fabrika Tedarik Süresi
- 10 Weeks
- Contact Current Rating
- 25A
- Reach Svhc
- Unknown
- Akım Değeri
- 25A
- Voltage Rated Dc
- 250V
- Weight
- 286g
- Terminal Stili
- Screw Terminal
- ECCN Kodu
- EAR99
- Body Breadth
- 17.45 mm
- Yayın Yılı
- 2001
- RoHS Durumu
- RoHS Compliant
- Mechanical Life
- 20,000,000 Cycles
- Current Rating Amps
- 25A AC
- Max Voltage Rating Ac
- 277V
