Specifications
- Orientation
- Straight
- Pretravel
- 0.120 (3.0mm)
- Weight
- 8g
- Pretravelmax
- 3.05 mm
- Electricallife
- 100,000 Cycles
- Current Rating Amps
- 1A AC
- Akım Değeri
- 1A
- Kurşunsuz
- Lead Free
- Kılıf / Paket
- 125
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Quick Connect
- Differential Travel
- 0.041 (1.05mm)
- Montaj Tipi
- Chassis Mount
- Depth
- 10.16mm
- Montaj
- Chassis Mount, Panel, Screw
- ECCN Kodu
- EAR99
- Max Current Rating
- 1A
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Voltage Rating Ac
- 125V
- Contact Materials
- Gold
- Overtravel
- 0.050 (1.27mm)
- Body Height
- 15.86mm
- Circuit
- SPDT
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 125V
- Actuator Travel
- 4.32 mm
- Actuator Type
- Lever, Roller
- Operating Position
- 0.806 (20.5mm)
- Yayın Yılı
- 2001
- Mechanical Life
- 10,000,000 Cycles
- HTS Kodu
- 8536.50.70.00
- Uzunluk
- 46.61mm
- Seri
- V7
- Ambalaj
- Bulk
- Switch Function
- On-Mom
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 141gf
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 9 Weeks
- Sealing
- CORROSION PROOF
