Specifications
- Seri
- V7
- Ambalaj
- Bulk
- Yayın Yılı
- 2008
- HTS Kodu
- 8536.50.70.00
- Release Force
- 28gf
- Voltage Rated Ac
- 277V
- Actuator Length
- 206mm
- Number Of Poles
- 1
- Parça Durumu
- Active
- Contact Dc Max Rating R Load
- A@VDC
- Onay Kuruluşu
- CE, CSA, UL
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 11A
- Electricallife
- 100,000 Cycles
- Current Rating Amps
- 11A AC 500mA DC
- Pretravel
- 0.055 (1.4mm)
- Weight
- 8g
- Overtravel
- 0.035 (0.9mm)
- ECCN Kodu
- EAR99
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Contact Currentdcmax
- 0.5A
- Montaj
- Chassis Mount, Screw
- Depth
- 10.16mm
- Reach Svhc
- No SVHC
- Contact Current Rating
- 11A
- Mechanical Life
- 10,000,000 Cycles
- Uzunluk
- 38.99mm
- Actuator Type
- Lever, Roller
- Operating Position
- 0.806 (20.5mm)
- Çalışma Sıcaklığı
- -40°C~85°C
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Fabrika Tedarik Süresi
- 4 Weeks
- Switch Function
- On-Mom
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 283gf
- Kurşunsuz
- Lead Free
- Kılıf / Paket
- 201
