Volume pricing
- 1+ pcs$1.32
- 10+ pcs$1.25
- 100+ pcs$1.18
- 500+ pcs$1.11
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Switch Function
- On-Mom
- Operating Force
- 227gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 6 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Polyester
- RoHS Durumu
- RoHS Compliant
- Voltage Rated Ac
- 125V
- Operating Position
- 0.579 (14.7mm)
- Actuator Type
- Round (Pin Plunger)
- Contact Current Rating
- 11A
- Mechanical Life
- 10,000,000 Cycles
- Yayın Yılı
- 2001
- Uzunluk
- 38.99mm
- Release Force
- 57gf
- HTS Kodu
- 8536.50.70.00
- Reach Svhc
- Unknown
- Ambalaj
- Bulk
- Seri
- V7
- Depth
- 10.16mm
- Voltage Rated Dc
- 125V
- Montaj
- Chassis Mount, Screw, Through Hole
- Yükseklik
- 23.72mm
- Contact Currentdcmax
- 0.5A
- Actuator Material
- Plastic
- Max Voltage Rating Dc
- 250V
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Current Rating
- 11A
- ECCN Kodu
- EAR99
- Contact Materials
- Gold, Silver
- Max Voltage Rating Ac
- 277V
- Pozisyon Sayısı
- 2
- Overtravel
- 0.040 (1.0mm)
- Kurşunsuz Kodu
- yes
- Circuit
- SPDT
- Pretravel
- 0.047 (1.2mm)
- Orientation
- Straight
- Weight
- 8g
- Current Rating Amps
- 11A AC 500mA DC
