Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Reach Svhc
- Unknown
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.579 (14.7mm)
- Contact Current Rating
- 10A
- Mechanical Life
- 10,000,000 Cycles
- Uzunluk
- 39.37mm
- Çalışma Sıcaklığı
- -40°C~85°C
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Switch Function
- On-Mom
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 50gf
- Fabrika Tedarik Süresi
- 10 Weeks
- Kurşunsuz
- Lead Free
- Differential Travel
- 0.010 (0.25mm)
- Orientation
- Straight
- Contact Ac Max Rating R Load
- 10A@277VAC
- Max Current Rating
- 10A
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 277V
- Contact Materials
- Silver
- Contact Timing
- SNAP ACTION
- Body Height
- 15.88mm
- Circuit
- SPDT
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 125V
- Actuator Material
- Plastic
- Seri
- V7
- Ambalaj
- Bulk
- Contact Ac Max Power Rating R Load
- 0.33HP@125VAC
- Voltage Rated Ac
- 125V
- Yayın Yılı
- 2001
- HTS Kodu
- 8536.50.70.00
- Release Force
- 5.000gf
- Contact Dc Max Rating R Load
- .5A@125VDC
- Parça Durumu
- Active
- Akım Değeri
- 10A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
