Volume pricing
- 1+ pcs$3.42
- 10+ pcs$3.23
- 100+ pcs$3.04
- 500+ pcs$2.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Actuator Material
- Plastic
- Contact Currentdcmax
- 0.5A
- Montaj
- Chassis Mount, Screw
- Voltage Rated Dc
- 125V
- Depth
- 10.16mm
- Circuit
- SPDT
- Kurşunsuz Kodu
- yes
- Overtravel
- 0.050 (1.27mm)
- Body Height
- 15.88mm
- Max Voltage Rating Ac
- 277V
- Contact Materials
- Gold, Silver
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 250V
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Current Rating
- 10A
- Pretravelmax
- 1.19 mm
- Electricallife
- 100,000 Cycles
- Current Rating Amps
- 10A AC 500mA DC
- Contact Ac Max Rating R Load
- 10A@277VAC
- Weight
- 8g
- Orientation
- Straight
- Pretravel
- 0.047 (1.2mm)
- Differential Travel
- 0.010 (0.25mm)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Akım Değeri
- 10A
- Fabrika Tedarik Süresi
- 12 Weeks
- Parça Durumu
- Active
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Dc Max Rating R Load
- .5A@125VDC
- Operating Force
- 50gf
- Switch Function
- On-Mom
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Çalışma Sıcaklığı
- -40°C~85°C
- HTS Kodu
- 8536.50.70.00
- Release Force
- 5.000gf
- Uzunluk
- 38.99mm
- Contact Current Rating
- 10A
