Volume pricing
- 1+ pcs$1.62
- 10+ pcs$1.53
- 100+ pcs$1.44
- 500+ pcs$1.36
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Pretravel
- 0.047 (1.2mm)
- Orientation
- Straight
- Weight
- 8g
- Contact Ac Max Rating R Load
- .1A@125VAC
- Current Rating Amps
- 100mA AC
- Electricallife
- 100,000 Cycles
- Pretravelmax
- 1.19 mm
- Akım Değeri
- 100mA
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kılıf / Paket
- 100
- Montaj Tipi
- Chassis Mount
- Differential Travel
- 0.010 (0.25mm)
- Terminal
- Quick Connect
- Depth
- 10.16mm
- Montaj
- Chassis Mount, Panel, Screw
- Actuator Material
- Plastic
- Max Current Rating
- 100mA
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- ECCN Kodu
- EAR99
- Max Voltage Rating Ac
- 125V
- Contact Materials
- Silver
- Contact Plating
- Gold
- Body Height
- 15.88mm
- Overtravel
- 0.050 (1.27mm)
- Kurşunsuz Kodu
- yes
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Operating Position
- 0.579 (14.7mm)
- Actuator Type
- Round (Pin Plunger)
- Yayın Yılı
- 2001
- Mechanical Life
- 10,000,000 Cycles
- HTS Kodu
- 8536.50.70.00
- Release Force
- 10gf
- Uzunluk
- 38.99mm
- Ambalaj
- Bulk
- Seri
- V7
- Switch Function
- On-Mom
- Operating Force
- 75gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Parça Durumu
- Active
