Volume pricing
- 1+ pcs$1.86
- 10+ pcs$1.75
- 100+ pcs$1.65
- 500+ pcs$1.56
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Fabrika Tedarik Süresi
- 8 Weeks
- Number Of Poles
- 1
- Parça Durumu
- Active
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Onay Kuruluşu
- CSA, UL, VDE
- Operating Force
- 150gf
- Switch Function
- On-Mom
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Çalışma Sıcaklığı
- -40°C~85°C
- Uzunluk
- 39.4mm
- Release Force
- 25gf
- HTS Kodu
- 8536.50.70.00
- Mechanical Life
- 10,000,000 Cycles
- Yayın Yılı
- 2001
- Contact Current Rating
- 100mA
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.579 (14.7mm)
- Voltage Rated Ac
- 125V
- Seri
- V7
- Ambalaj
- Bulk
- Reach Svhc
- Unknown
- Actuator Material
- Plastic
- Montaj
- Chassis Mount, Panel, Screw
- Depth
- 10.16mm
- Circuit
- SPDT
- Kurşunsuz Kodu
- yes
- Overtravel
- 0.050 (1.27mm)
- Contact Plating
- Gold
- Pozisyon Sayısı
- 2
- Contact Materials
- Gold, Silver
- Max Voltage Rating Ac
- 125V
- ECCN Kodu
- EAR99
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Current Rating
- 100mA
- Electricallife
- 100,000 Cycles
- Current Rating Amps
- 100mA AC
- Weight
- 8g
- Orientation
- Straight
- Pretravel
- 0.047 (1.2mm)
