Specifications
- Contact Ac Max Rating R Load
- 15.1A@277VAC
- Orientation
- Straight
- Differential Travel
- 0.010 (0.25mm)
- Actuator Material
- Plastic
- Voltage Rated Dc
- 125V
- Body Height
- 15.88mm
- Kurşunsuz Kodu
- yes
- Circuit
- SPST-NC
- Max Current Rating
- 15.1A
- Max Voltage Rating Dc
- 250V
- Max Voltage Rating Ac
- 277V
- Contact Materials
- Silver
- Contact Current Rating
- 15A
- Mechanical Life
- 10,000,000 Cycles
- Uzunluk
- 38.99mm
- Operating Position
- 0.579 (14.7mm)
- Actuator Type
- Round (Pin Plunger)
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 10 Weeks
- Switch Function
- On-Mom
- Operating Force
- 150gf
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Polyester
- RoHS Durumu
- RoHS Compliant
- Current Rating Amps
- 15A AC 500mA DC
- Pretravelmax
- 1.19 mm
- Electricallife
- 100,000 Cycles
- Pretravel
- 0.047 (1.2mm)
- Weight
- 8g
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Throw Configuration
- SPST
- Montaj Tipi
- Chassis Mount
- Terminal
- Quick Connect
- Akım Değeri
- 15A
- Montaj
- Chassis Mount, Screw
- Contact Currentdcmax
- 0.5A
- Depth
- 10.16mm
- Overtravel
- 0.050 (1.27mm)
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
