Specifications
- Depth
- 10.16mm
- Voltage Rated Dc
- 125V
- Contact Currentdcmax
- 0.5A
- Montaj
- Chassis Mount, Panel, Screw
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 250V
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Current Rating
- 15.1A
- Max Voltage Rating Ac
- 277V
- Contact Materials
- Silver
- Overtravel
- 0.050 (1.27mm)
- Body Height
- 15.88mm
- Circuit
- SPST-NO
- Kurşunsuz Kodu
- yes
- Orientation
- Straight
- Pretravel
- 0.047 (1.2mm)
- Weight
- 8g
- Contact Ac Max Rating R Load
- 15.1A@277VAC
- Electricallife
- 100,000 Cycles
- Pretravelmax
- 1.19 mm
- Current Rating Amps
- 15A AC 500mA DC
- Akım Değeri
- 15A
- Throw Configuration
- SPST
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 0.010 (0.25mm)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
- Switch Function
- Off-Mom
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Dc Max Rating R Load
- .5A@125VDC
- Operating Force
- 150gf
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 13 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Voltage Rated Ac
- 125V
- Actuator Travel
- 2.46 mm
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.579 (14.7mm)
