Volume pricing
- 1+ pcs$3.68
- 10+ pcs$3.47
- 100+ pcs$3.27
- 500+ pcs$3.09
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 10.16mm
- Voltage Rated Dc
- 125V
- Montaj
- Chassis Mount, Panel, Screw
- Contact Currentdcmax
- 0.5A
- Max Voltage Rating Dc
- 250V
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Current Rating
- 15.1A
- ECCN Kodu
- EAR99
- Contact Materials
- Silver
- Max Voltage Rating Ac
- 277V
- Body Height
- 15.88mm
- Overtravel
- 0.050 (1.27mm)
- Kurşunsuz Kodu
- yes
- Circuit
- SPST-NO
- Pretravel
- 0.047 (1.2mm)
- Orientation
- Straight
- Weight
- 8g
- Contact Ac Max Rating R Load
- 15.1A@277VAC
- Current Rating Amps
- 15A AC 500mA DC
- Electricallife
- 100,000 Cycles
- Pretravelmax
- 1.19 mm
- Akım Değeri
- 15A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Throw Configuration
- SPST
- Montaj Tipi
- Chassis Mount
- Differential Travel
- 0.010 (0.25mm)
- Terminal
- Quick Connect
- Switch Function
- Off-Mom
- Operating Force
- 150gf
- Contact Dc Max Rating R Load
- .5A@125VDC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 9 Weeks
- Çalışma Sıcaklığı
- -40°C~85°C
- Housing Material
- Polyester
- RoHS Durumu
- RoHS Compliant
- Voltage Rated Ac
- 125V
- Actuator Travel
- 2.46 mm
- Operating Position
- 0.579 (14.7mm)
- Actuator Type
- Round (Pin Plunger)
