Volume pricing
- 1+ pcs$1.17
- 10+ pcs$1.10
- 100+ pcs$1.04
- 500+ pcs$0.98
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Ac Max Rating R Load
- 11A@277VAC
- Orientation
- Straight
- Differential Travel
- 0.010 (0.25mm)
- Actuator Material
- Plastic
- Voltage Rated Dc
- 125V
- Circuit
- SPST-NC
- Kurşunsuz Kodu
- yes
- Body Height
- 15.88mm
- Contact Timing
- SNAP ACTION
- Contact Materials
- Silver
- Max Voltage Rating Ac
- 277V
- Max Voltage Rating Dc
- 250V
- Max Current Rating
- 11A
- Uzunluk
- 38.61mm
- Mechanical Life
- 10,000,000 Cycles
- Contact Current Rating
- 11A
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.579 (14.7mm)
- Fabrika Tedarik Süresi
- 6 Weeks
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 150gf
- Switch Function
- On-Mom
- RoHS Durumu
- RoHS Compliant
- Housing Material
- Polyester
- Çalışma Sıcaklığı
- -40°C~85°C
- Pretravelmax
- 1.19 mm
- Electricallife
- 100,000 Cycles
- Current Rating Amps
- 11A AC 500mA DC
- Weight
- 8g
- Pretravel
- 0.047 (1.2mm)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Throw Configuration
- SPST
- Akım Değeri
- 11A
- Contact Currentdcmax
- 0.5A
- Montaj
- Chassis Mount, Screw
- Depth
- 10.16mm
- Overtravel
- 0.050 (1.27mm)
- ECCN Kodu
- EAR99
