Specifications
- Contact Ac Max Rating R Load
- 5A@277VAC
- Electricallife
- 100,000 Cycles
- Pretravelmax
- 1.19 mm
- Current Rating Amps
- 5A AC
- Orientation
- Straight
- Pretravel
- 0.047 (1.2mm)
- Weight
- 8g
- Throw Configuration
- SPST
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Differential Travel
- 0.010 (0.25mm)
- Terminal
- Quick Connect
- Montaj Tipi
- Chassis Mount
- Akım Değeri
- 5A
- Montaj
- Chassis Mount, Panel, Screw
- Actuator Material
- Plastic
- Depth
- 10.16mm
- Overtravel
- 0.050 (1.27mm)
- Body Height
- 15.88mm
- Circuit
- SPST-NO
- Kurşunsuz Kodu
- yes
- ECCN Kodu
- EAR99
- Max Current Rating
- 5A
- Terminal Stili
- Quick Connect - 0.187 (4.7mm)
- Max Voltage Rating Ac
- 277V
- Contact Materials
- Silver
- Mechanical Life
- 10,000,000 Cycles
- Yayın Yılı
- 2015
- Uzunluk
- 38.99mm
- Release Force
- 25gf
- HTS Kodu
- 8536.50.70.00
- Voltage Rated Ac
- 125V
- Actuator Type
- Round (Pin Plunger)
- Operating Position
- 0.579 (14.7mm)
- Seri
- V7
- Ambalaj
- Bulk
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 10 Weeks
- Switch Function
- Off-Mom
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 150gf
