Specifications
- Overtravel
- 0.040 (1.0mm)
- RoHS Durumu
- Non-RoHS Compliant
- Kurşunsuz
- Contains Lead
- Parça Durumu
- Active
- ECCN Kodu
- EAR99
- Electricallife
- 25,000 Cycles
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Operating Force
- 170 ~ 397gf
- Pretravel
- 0.047 (1.2mm)
- Switch Function
- On-Mom
- Voltage Rated Dc
- 28V
- Uzunluk
- 34.6mm
- Montaj
- Chassis Mount, Panel, Screw
- Depth
- 10.2mm
- Actuator Type
- Round (Pin Plunger)
- Body Breadth
- 10.16 mm
- Fabrika Tedarik Süresi
- 6 Weeks
- Montaj Tipi
- Chassis Mount
- Current Rating Amps
- 10A AC/DC
- Seri
- V3
- Terminal
- Screw
- Max Current Rating
- 10A
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Mechanical Life
- 25,000 Cycles
- Pretravelmax
- 1.19 mm
- Body Height
- 15.87mm
- Operating Position
- 0.579 (14.7mm)
- Yayın Yılı
- 1999
- Orientation
- Straight
- Contact Current Rating
- 10A
- Circuit
- SPDT
- Pozisyon Sayısı
- 2
- Differential Travel
- 0.016 (0.4mm)
- Akım Değeri
- 10A
- Terminal Stili
- Screw Terminal
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Release Force
- 113gf
- Voltage Rated Ac
- 115V
- Reach Svhc
- Unknown
