Volume pricing
- 1+ pcs$16.61
- 10+ pcs$15.67
- 100+ pcs$14.79
- 500+ pcs$13.95
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Currentdcmax
- 0.5A
- Differential Travel
- 0.016 (0.4mm)
- Pozisyon Sayısı
- 2
- Max Voltage Rating Dc
- 250V
- Circuit
- SPDT
- Orientation
- Straight
- Kurşunsuz Kodu
- yes
- Genişlik
- 27.7mm
- Operating Position
- 0.579 (14.7mm)
- Contact Current Rating
- 15.1A
- Reach Svhc
- Unknown
- Max Voltage Rating Ac
- 250V
- Flammability Rating
- UL94 V-0
- Terminal Stili
- Screw Terminal
- Akım Değeri
- 15A
- Weight
- 7.71g
- Release Force
- 113gf
- Voltage Rated Ac
- 125V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Force
- 170 ~ 397gf
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- ECCN Kodu
- EAR99
- Uzunluk
- 34.65mm
- Voltage Rated Dc
- 125V
- Switch Function
- On-Mom
- Pretravel
- 0.047 (1.2mm)
- Overtravel
- 0.040 (1.0mm)
- Onay Kuruluşu
- CSA, UL
- Contact Currentacmax
- 5A
- Number Of Poles
- 1
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- HTS Kodu
- 8536.50.70.00
- Max Current Rating
- 15.1A
- Terminal
- Screw
- Current Rating Amps
- 15A AC 500mA DC
- Seri
- V3
- Ambalaj
- Bulk
- Actuator Material
- Plastic
- Actuator Type
- Round (Pin Plunger)
