Honeywell Sensing and Productivity Solutions
V15T16-CC100-K
Snap Action Switches
In StockRoHS: Compliant
Volume pricing
- 1+ pcs$3.18
- 10+ pcs$3.00
- 100+ pcs$2.83
- 500+ pcs$2.67
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Operating Force
- 100gf
- Electricallife
- 50,000 Cycles
- Depth
- 10.3mm
- Terminal
- Quick Connect
- Parça Durumu
- Active
- Montaj
- Chassis Mount, Panel, Screw
- Akım Değeri
- 16A
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 2007
- Seri
- V15
- Overtravel
- 0.030 (0.76mm)
- Circuit
- SPST-NC
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Differential Travel
- 0.016 (0.4mm)
- Actuator Type
- Round (Pin Plunger)
- Contact Materials
- Cadmium, Silver
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 9 Weeks
- HTS Kodu
- 8536.50.70.00
- Mechanical Life
- 5,000,000 Cycles
- Operating Position
- 0.579 (14.7mm)
- Voltage Rated Ac
- 250V
- Çalışma Sıcaklığı
- -25°C~125°C
- ECCN Kodu
- EAR99
- Current Rating Amps
- 16A AC
- Weight
- 5g
- Pretravel
- 0.063 (1.6mm)
- Orientation
- Straight
- Body Height
- 15.9mm
- Uzunluk
- 39.7mm
- Housing Material
- PBT
- Reach Svhc
- Unknown
- Throw Configuration
- SPST
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Contact Ac Max Rating R Load
- 16A@250VAC
- Release Force
- 25gf
- Max Current Rating
- 16A
- Max Voltage Rating Ac
- 250V
