Honeywell Sensing and Productivity Solutions
V15H22-CZ400B06-K
Snap Action Switches
In StockRoHS: Compliant
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Circuit
- SPDT
- Overtravel
- 0.087 (2.2mm)
- Seri
- V15
- Yayın Yılı
- 2009
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Chassis Mount, Screw
- Akım Değeri
- 22A
- Depth
- 10.3mm
- Terminal
- Quick Connect
- Parça Durumu
- Active
- Electricallife
- 10,000 Cycles
- Operating Force
- 130gf
- Voltage Rated Ac
- 250V
- Operating Position
- 0.812 (20.6mm)
- Mechanical Life
- 5,000,000 Cycles
- Fabrika Tedarik Süresi
- 25 Weeks
- HTS Kodu
- 8536.50.70.00
- RoHS Durumu
- RoHS Compliant
- Switch Function
- On-Mom
- Montaj Tipi
- Chassis Mount
- Contact Materials
- Cadmium, Silver
- Body Length Or Diameter
- 27.8mm
- Actuator Type
- Lever, Roller
- Differential Travel
- 0.062 (1.6mm)
- Terminal Stili
- Quick Connect - 0.250 (6.3mm)
- Housing Material
- Polyester
- Body Height
- 15.9mm
- Orientation
- Straight
- Pretravel
- 0.236 (6.0mm)
- REACH Uyumluluk Kodu
- unknown
- Weight
- 5g
- Çalışma Sıcaklığı
- -25°C~150°C
- Current Rating Amps
- 22A AC
- ECCN Kodu
- EAR99
- Ambalaj
- Bulk
- Max Voltage Rating Ac
- 250V
- Release Force
- 20gf
- Contact Ac Max Rating R Load
- 22A@250VAC
- Switch Type
- SNAP ACTING/LIMIT SWITCH
