Specifications
- Body Height
- 116.8mm
- Voltage Rated Ac
- 120V
- Pretravel
- 0.070 (1.78mm)
- Akım Değeri
- 10A
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Conduit
- Mounting Feature
- PANEL MOUNT
- Fabrika Tedarik Süresi
- 26 Weeks
- Housing Material
- Aluminium
- Çalışma Sıcaklığı
- -12°C~93°C
- Parça Durumu
- Active
- Differential Travel
- 0.015 (0.38mm)
- Contact Ac Max Rating R Load
- 10A@600VAC
- Current Rating Amps
- 10A AC 800mA DC
- Operating Force
- 1814gf
- Sealing
- EXPLOSION PROOF
- Pretravelmax
- 1.78 mm
- Contact Voltagedcmax
- 240V
- Terminal Kaplaması
- Silver (Ag)
- Voltage Rated Dc
- 115V
- Circuit
- SPDT (DB/DM)
- Throw Configuration
- SPDT
- Özellikler
- Roller Perpendicular to Mounting Surface
- RoHS Durumu
- RoHS Compliant
- REACH Uyumluluk Kodu
- unknown
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Roller Plunger
- Overtravel
- 0.190 (4.8mm)
- Yayın Yılı
- 2014
- Body Length Or Diameter
- 50.8mm
- Seri
- LSX
- Yüzey Montaj
- NO
- JESD-609 Kodu
- e4
- Operating Position
- 2.700 (68.6mm)
- Montaj Tipi
- Chassis Mount
- Actuator Travel
- 6.61 mm
- Contact Dc Max Rating R Load
- 10A@240VDC
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
