Volume pricing
- 1+ pcs$399.84
- 10+ pcs$377.21
- 100+ pcs$355.86
- 500+ pcs$335.72
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Depth
- 72.99mm
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Body Breadth
- 41.4 mm
- Contact Current Rating
- 10A
- Contact Dc Max Rating R Load
- 10A@240VDC
- Actuator Travel
- 6.61 mm
- JESD-609 Kodu
- e4
- Operating Position
- 2.305 (58.5mm)
- Montaj Tipi
- Chassis Mount
- Uzunluk
- 76.2mm
- Reach Svhc
- No SVHC
- Orientation
- Straight
- Yükseklik
- 155.45mm
- Overtravel
- 0.190 (4.8mm)
- Yayın Yılı
- 2011
- Seri
- LSX
- RoHS Durumu
- RoHS Compliant
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Round (Pin Plunger)
- Genişlik
- 156.7mm
- ECCN Kodu
- EAR99
- Circuit
- SPDT (DB/DM)
- Throw Configuration
- SPDT
- Özellikler
- Explosion Proof
- Contact Voltageacmax
- 600V
- Voltage Rated Dc
- 115V
- Operating Force
- 1814gf
- Pretravelmax
- 1.78 mm
- Contact Voltagedcmax
- 240V
- Terminal Kaplaması
- Silver (Ag)
- Differential Travel
- 0.015 (0.38mm)
- Contact Ac Max Rating R Load
- 10A@600VAC
- Current Rating Amps
- 10A AC 800mA DC
- Fabrika Tedarik Süresi
- 4 Weeks
- Housing Material
- Aluminium
- Montaj
- Chassis Mount, Screw
- Çalışma Sıcaklığı
- -12°C~93°C
- Parça Durumu
- Obsolete
- Onay Kuruluşu
- CSA, UL
