Volume pricing
- 1+ pcs$492.13
- 10+ pcs$464.28
- 100+ pcs$438.00
- 500+ pcs$413.20
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- JESD-609 Kodu
- e4
- Montaj Tipi
- Chassis Mount
- Body Breadth
- 41.4 mm
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Contact Dc Max Rating R Load
- 10A@240VDC
- RoHS Durumu
- RoHS Compliant
- Actuator Type
- Side Rotary, Roller
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Circuit
- DPDT (DB/DM)
- ECCN Kodu
- EAR99
- Özellikler
- Nylon Roller, Front Mounted
- Contact Voltageacmax
- 600V
- Throw Configuration
- DPDT
- Orientation
- Right Angle
- Overtravel
- 60°
- Body Length Or Diameter
- 50.8mm
- Yayın Yılı
- 2016
- Seri
- LSX
- Differential Travel
- 7°
- Contact Ac Max Rating R Load
- 10A@600VAC
- Current Rating Amps
- 10A AC 800mA DC
- Fabrika Tedarik Süresi
- 20 Weeks
- Housing Material
- Aluminium
- Montaj
- Chassis Mount, Screw
- Onay Kuruluşu
- CSA, UL
- Çalışma Sıcaklığı
- -12°C~121°C
- Parça Durumu
- Active
- Voltage Rated Dc
- 115V
- Operating Force
- 46gfm
- Terminal Kaplaması
- Silver (Ag)
- Contact Voltagedcmax
- 240V
- Sealing
- EXPLOSION PROOF
- Voltage Rated Ac
- 120V
- Akım Değeri
- 10A
- Pretravel
- 15°
- Body Height
- 116.8mm
- HTS Kodu
- 8536.50.70.00
- Ambalaj
- Bulk
- Terminal
- Conduit
