Specifications
- Parça Durumu
- Active
- Genişlik
- 47.625mm
- Akım Değeri
- 10A
- Fabrika Tedarik Süresi
- 20 Weeks
- ECCN Kodu
- EAR99
- Terminal
- Conduit
- Çalışma Sıcaklığı
- -12°C~121°C
- Switch Function
- On-Mom
- Yayın Yılı
- 2005
- Max Voltage Rating Dc
- 240V
- Seri
- HDLS
- Montaj Tipi
- Chassis Mount
- Max Voltage Rating Ac
- 600V
- Ambalaj
- Bulk
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Sealing
- EPOXY TERMINAL SEALED; IP65; IP66; IP67
- Material
- Stainless Steel
- Housing Material
- Stainless Steel
- Voltage Rated Ac
- 600V
- Pretravel
- 15°
- Contact Current Rating
- 10A
- Number Of Poles
- 2
- Depth
- 61.8998mm
- Operating Force
- 46gfm
- Özellikler
- Stainless Steel
- Uzunluk
- 122.96mm
- RoHS Durumu
- RoHS Compliant
- Actuator Type
- Side Rotary - No Lever
- Voltage Rated Dc
- 120V
- Reach Svhc
- No SVHC
- Throw Configuration
- DPDT
- Terminal Stili
- Screw Terminal
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Montaj
- Chassis Mount, Screw
- Contact Ac Max Rating R Load
- 10A@600VAC
- Orientation
- Right Angle
- Current Rating Amps
- 10A AC 800mA DC
- Overtravel
- 60°
- Differential Travel
- 7°
- Circuit
- DPDT (DB/DM)
