HOA6991-L51

Specifications

Sensing Method

Through-Beam

Reverse Voltage Dc

3V

Montaj Tipi

Chassis Mount

Number Of Channels

1

Reverse Breakdown Voltage

3V

Output Configuration

NPN - Open Collector, Buffer

Algılama Mesafesi

0.125 (3.18mm)

Pin Sayısı

5

Operating Supply Voltage

12V

High Level Output Current

100μA

Housing Material

Polysulfone

Min. Çalışma Sıcaklığı

-40°C

Parça Durumu

Obsolete

Output Voltage

400mV

Power Dissipation

100mW

Forward Voltage

1.6V

Çalışma Sıcaklığı

-40°C~70°C TA

Rise Time

70ns

Low Level Output Current

12.8mA

Montaj

Chassis Mount, Screw

Yayın Yılı

1997

Current Supply

15mA

RoHS Durumu

RoHS Compliant

Number Of Elements

1

Nem Hassasiyeti (MSL)

1 (Unlimited)

Fall Time Typ

70 ns

Besleme Gerilimi

4.5V~12V

Response Time

70ns

Maks. Çalışma Sıcaklığı

70°C

Ambalaj

Bulk

Kılıf / Paket

Module, Pre-Wired

Operating Supply Current

15mA

Fabrika Tedarik Süresi

6 Weeks

Propagation Delay

5 μs

Input Current

50mA

Forward Current

50mA
