Specifications
- Terminal Stili
- Screw Terminal
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Max Voltage Rating Ac
- 600V
- Yayın Yılı
- 1998
- Yükseklik
- 85mm
- Uzunluk
- 65mm
- Montaj Tipi
- Chassis Mount
- Montaj
- Chassis Mount, Screw
- Reach Svhc
- No SVHC
- Akım Değeri
- 6A
- Circuit
- SPDT
- Seri
- GLS
- Kılıf / Paket
- 300
- Onay Kuruluşu
- CCC, CE, CSA, UL
- ECCN Kodu
- EAR99
- Genişlik
- 65mm
- Operating Position
- 0.710 (18.0mm)
- Ambalaj
- Bulk
- Operating Force
- 1632gf
- Current Rating Amps
- 6A AC 550mA DC
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Parça Durumu
- Active
- Terminal
- Screw
- Fabrika Tedarik Süresi
- 18 Weeks
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 125V
- Pretravel
- 0.120 (3.0mm)
- Switch Function
- On-Mom
- Çalışma Sıcaklığı
- -40°C~85°C
- Hole Diameter
- 4.3 mm
- HTS Kodu
- 8536.50.70.00
- Contact Current Rating
- 10A
- Orientation
- Straight
- Contact Dc Max Rating R Load
- 10A@250VDC
- Housing Material
- Zinc
- Max Voltage Rating Dc
- 250V
- Voltage Rated Ac
- 120V
- Overtravel
- 0.118 (3.0mm)
- Mechanical Life
- 15,000,000 Cycles
