Specifications
- Actuator Travel
- 6 mm
- Terminal Stili
- Screw Terminal
- Yayın Yılı
- 2001
- Max Voltage Rating Ac
- 600V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Yükseklik
- 89.5mm
- Uzunluk
- 30.5mm
- Montaj Tipi
- Chassis Mount
- Montaj
- Chassis Mount, Screw
- Reach Svhc
- No SVHC
- Contact Currentacmax
- 10A
- Akım Değeri
- 6A
- Circuit
- SPDT
- Seri
- GLS
- Kılıf / Paket
- 600
- Onay Kuruluşu
- CCC, CE, CSA, UL
- ECCN Kodu
- EAR99
- Operating Position
- 1.100 (28.0mm)
- Ambalaj
- Bulk
- Genişlik
- 30.5mm
- Current Rating Amps
- 6A AC 550mA DC
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Operating Force
- 1632gf
- Parça Durumu
- Active
- Fabrika Tedarik Süresi
- 18 Weeks
- Terminal
- Screw
- RoHS Durumu
- RoHS Compliant
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Voltage Rated Dc
- 125V
- Switch Function
- On-Mom
- Pretravel
- 0.120 (3.0mm)
- Hole Diameter
- 4.3 mm
- HTS Kodu
- 8536.50.70.00
- Çalışma Sıcaklığı
- -40°C~85°C
- Contact Dc Max Rating R Load
- 10A@250VDC
- Orientation
- Straight
- Voltage Rated Ac
- 120V
- Max Voltage Rating Dc
- 250V
- Housing Material
- Plastic
- Overtravel
- 0.118 (3.0mm)
