Specifications
- Çalışma Sıcaklığı
- -40°C~85°C
- Voltage Rated Dc
- 125V
- Switch Function
- On-Mom
- Özellikler
- Nylon Roller
- Kurşunsuz
- Lead Free
- Orientation
- Right Angle
- Genişlik
- 30mm
- Actuator Type
- Side Rotary, Adjustable Roller
- Max Voltage Rating Ac
- 240V
- Pretravel
- 26°
- Uzunluk
- 30.5mm
- Mechanical Life
- 10,000,000 Cycles
- Contact Current Rating
- 10A
- Onay Kuruluşu
- CCC, CE, CSA, UL
- Parça Durumu
- Active
- Voltage Rated Ac
- 300V
- Yükseklik
- 147mm
- ECCN Kodu
- EAR99
- Terminal
- Conduit
- Ambalaj
- Bulk
- Fabrika Tedarik Süresi
- 18 Weeks
- Overtravel
- 49°
- Montaj Tipi
- Chassis Mount
- Pozisyon Sayısı
- 2
- Max Voltage Rating Dc
- 250V
- Differential Travel
- 12°
- Circuit
- SPDT
- HTS Kodu
- 8536.50.70.00
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Depth
- 44.2mm
- Housing Material
- Zinc
- Current Rating Amps
- 6A AC 550mA DC
- Akım Değeri
- 10A
- Operating Force
- 12gfm
- Seri
- GLS
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- 120
- Yayın Yılı
- 2001
- Number Of Poles
- 1
