Specifications
- Body Height
- 82mm
- Uzunluk
- 42mm
- Pretravel
- 26°
- Max Voltage Rating Ac
- 600V
- Actuator Type
- Side Rotary, Adjustable Rod
- Genişlik
- 42mm
- Orientation
- Right Angle
- Switch Function
- On-Mom
- Voltage Rated Dc
- 125V
- Çalışma Sıcaklığı
- -25°C~85°C
- Outside Diameter
- 5.3 mm
- Contact Current Rating
- 10A
- Mechanical Life
- 15,000,000 Cycles
- Ambalaj
- Bulk
- Terminal
- Plug
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 120V
- Parça Durumu
- Active
- Onay Kuruluşu
- CE, CSA, UL
- Contact Currentacmax
- 6A
- Overtravel
- 59°
- Contact Ac Max Rating R Load
- 6A@120VAC
- Fabrika Tedarik Süresi
- 27 Weeks
- Circuit
- SPDT
- HTS Kodu
- 8536.50.70.00
- Differential Travel
- 12°
- Max Voltage Rating Dc
- 250V
- Montaj Tipi
- Chassis Mount
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- Metal
- Ingress Protection
- IP67 - Dust Tight, Waterproof
- Operating Force
- 33gfm
- Seri
- GLS
- Akım Değeri
- 6A
- Current Rating Amps
- 6A AC 550mA DC
- Housing Material
- Zinc
- Depth
- 62mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Yayın Yılı
- 1998
- Contact Currentdcmax
- 0.55A
