Specifications
- Uzunluk
- 92.96mm
- Max Current Rating
- 15A
- Operating Position
- 4.722 m
- Montaj Tipi
- Chassis Mount
- Actuator Travel
- 5.56 mm
- Depth
- 68.707mm
- Terminal Stili
- Wire Leads
- Switch Function
- On-On
- Body Breadth
- 65.02 mm
- Circuit
- SPDT
- Maks. Çalışma Sıcaklığı
- 71°C
- ECCN Kodu
- EAR99
- Contact Voltageacmax
- 480V
- Özellikler
- Explosion Proof
- RoHS Durumu
- RoHS Compliant
- Kılıf / Paket
- 125
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Type
- Side Rotary, Roller
- Genişlik
- 78.486mm
- Overtravel
- 90°
- Yayın Yılı
- 2005
- Min. Çalışma Sıcaklığı
- -40°C
- Kurşunsuz Kodu
- yes
- Seri
- EX
- Orientation
- Right Angle
- Fabrika Tedarik Süresi
- 20 Weeks
- Montaj
- Chassis Mount, Screw
- Housing Material
- Aluminium
- Parça Durumu
- Active
- Current Rating Amps
- 15A AC 500mA DC
- Contact Ac Max Rating R Load
- 15A@480VAC
- Operating Force
- 340gf
- Max Voltage Rating Dc
- 250V
- Pretravelmax
- 5.56 mm
- Voltage Rated Dc
- 125V
- Contact Currentdcmax
- 0.5A
- Body Height
- 51.18mm
- Voltage Rated Ac
- 125V
- Akım Değeri
- 15A
- Pretravel
- 0.219 (5.6mm)
