Specifications
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Contact Currentacmax
- 5A
- Parça Durumu
- Active
- Kurşunsuz Kodu
- yes
- Actuator Travel
- 6.76 mm
- Yayın Yılı
- 2005
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Terminal Stili
- Screw Terminal
- Çalışma Sıcaklığı
- -40°C~71°C
- Depth
- 51.18mm
- Voltage Rated Dc
- 125V
- Contact Ac Max Rating R Load
- 5A@480VAC
- Max Current Rating
- 15A
- Montaj Tipi
- Chassis Mount
- Contact Voltageacmax
- 480V
- Genişlik
- 65.02mm
- Contact Currentdcmax
- 0.5A
- Terminal
- Conduit
- Housing Material
- Aluminium
- Uzunluk
- 92.96mm
- Pretravel
- 0.219 (5.6mm)
- Switch Function
- On-Mom
- RoHS Durumu
- RoHS Compliant
- Number Of Poles
- 1
- Özellikler
- Explosion Proof
- Differential Travel
- 0.007 (0.18mm)
- Actuator Type
- Side Rotary, Roller
- Current Rating Amps
- 15A AC 500mA DC
- Overtravel
- 90°
- Pozisyon Sayısı
- 2
- ECCN Kodu
- EAR99
- Circuit
- SPDT
- Voltage Rated Ac
- 125V
- Seri
- EX
- Onay Kuruluşu
- CSA, UL
- Montaj
- Chassis Mount
- HTS Kodu
- 8536.50.70.00
- Operating Force
- 227 ~ 567gf
- Fabrika Tedarik Süresi
- 20 Weeks
- Akım Değeri
- 15A
