Specifications
- Contact Voltageacmax
- 250V
- Yayın Yılı
- 2008
- Seri
- DTF
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Overtravel
- 0.219 (5.6mm)
- Circuit
- DPDT
- Operating Force
- 1134gf
- Parça Durumu
- Active
- Depth
- 54.86mm
- Terminal
- Conduit
- Montaj
- Chassis Mount
- Akım Değeri
- 10A
- Actuator Material
- STEEL
- RoHS Durumu
- RoHS Compliant
- Fabrika Tedarik Süresi
- 20 Weeks
- HTS Kodu
- 8536.50.70.00
- Contact Currentdcmax
- 0.3A
- Voltage Rated Ac
- 125V
- Terminal Stili
- Screw Terminal
- Differential Travel
- 0.120 (3.05mm)
- Actuator Type
- Lever, Roller
- Özellikler
- Actuator Mounted Left Side
- Montaj Tipi
- Chassis Mount
- Body Breadth
- 24.89 mm
- Switch Function
- On-Mom
- Uzunluk
- 101.6mm
- Housing Material
- Aluminium
- Reach Svhc
- No SVHC
- Genişlik
- 33.02mm
- Contact Dc Max Rating R Load
- .3A@125VDC
- Çalışma Sıcaklığı
- -32°C~71°C
- ECCN Kodu
- EAR99
- Current Rating Amps
- 10A AC 300mA DC
- Pretravel
- 0.310 (7.9mm)
- Actuator Travel
- 13.49 mm
- Release Force
- 57gf
- Kurşunsuz Kodu
- yes
- Contact Ac Max Rating R Load
- 10A@250VAC
- Ambalaj
- Bulk
- Max Current Rating
- 10A
