Volume pricing
- 1+ pcs$84.97
- 10+ pcs$80.16
- 100+ pcs$75.62
- 500+ pcs$71.34
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Parça Durumu
- Active
- Body Height
- 31.24mm
- Terminal
- Screw
- Body Breadth
- 17.45 mm
- RoHS Durumu
- RoHS Compliant
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Current Rating Amps
- 10A AC 300mA DC
- Actuator Type
- Lever, Roller
- Voltage Rated Dc
- 125V
- HTS Kodu
- 8536.50.70.00
- Overtravel
- 0.005 (0.13mm)
- Contact Dc Max Rating R Load
- .3A@125VDC
- Depth
- 17.5mm
- Akım Değeri
- 10A
- Contact Currentdcmax
- 0.3A
- Differential Travel
- 0.085 (2.16mm)
- Operating Force
- 255 ~ 425gf
- Pretravelmax
- 3.3 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Length
- 300mm
- Housing Material
- Phenolic
- Actuator Travel
- 3.43 mm
- Fabrika Tedarik Süresi
- 10 Weeks
- Reach Svhc
- Unknown
- Material
- Plastic
- ECCN Kodu
- EAR99
- Voltage Rated Ac
- 125V
- Max Current Rating
- 10A
- Seri
- DT
- Contact Ac Max Rating R Load
- 10A@250VAC
- Pretravel
- 0.131 (3.3mm)
- Max Voltage Rating Dc
- 250V
- Onay Kuruluşu
- CSA, UL
- Çalışma Sıcaklığı
- -55°C~85°C
- Operating Position
- 1.156 (29.4mm)
- Max Voltage Rating Ac
- 250V
- Release Force
- 43gf
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
