Specifications
- Parça Durumu
- Active
- RoHS Durumu
- RoHS Compliant
- Body Breadth
- 17.45 mm
- Terminal
- Screw
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Voltage Rated Dc
- 125V
- Current Rating Amps
- 10A AC 300mA DC
- Actuator Type
- Round (Pin Plunger)
- HTS Kodu
- 8536.50.70.00
- Differential Travel
- 0.060 (1.5mm)
- Contact Currentdcmax
- 0.3A
- Akım Değeri
- 10A
- Overtravel
- 0.005 (0.13mm)
- Depth
- 17.5mm
- Operating Force
- 340 ~ 567gf
- Pretravelmax
- 1.91 mm
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Reach Svhc
- Unknown
- Fabrika Tedarik Süresi
- 8 Weeks
- Housing Material
- Phenolic
- Max Current Rating
- 10A
- Voltage Rated Ac
- 125V
- ECCN Kodu
- EAR99
- Max Voltage Rating Dc
- 250V
- Yükseklik
- 32.4mm
- Pretravel
- 0.075 (1.9mm)
- Seri
- DT
- Onay Kuruluşu
- CSA, UL
- Operating Position
- 0.615 (15.6mm)
- Max Voltage Rating Ac
- 250V
- Çalışma Sıcaklığı
- -55°C~85°C
- Ambalaj
- Bulk
- Kurşunsuz
- Contains Lead
- Release Force
- 57gf
- Orientation
- Straight
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Montaj
- Chassis Mount, Screw
- Pozisyon Sayısı
- 2
- Uzunluk
- 49.3mm
