Volume pricing
- 1+ pcs$261.04
- 10+ pcs$246.26
- 100+ pcs$232.32
- 500+ pcs$219.17
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Contact Dc Max Rating R Load
- .5A@125VDC
- Release Force
- 113gf
- REACH Uyumluluk Kodu
- unknown
- Montaj
- Chassis Mount, Flanges
- ECCN Kodu
- EAR99
- Montaj Tipi
- Chassis Mount
- Pretravelmax
- 0.38 mm
- RoHS Durumu
- RoHS Compliant
- Max Voltage Rating Ac
- 240V
- Circuit
- SPDT
- Overtravel
- 0.141 (3.6mm)
- HTS Kodu
- 8536.50.70.00
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Current Rating Amps
- 15A AC 500mA DC
- Operating Force
- 255 ~ 368gf
- Body Height
- 44.45mm
- Terminal Stili
- Screw Terminal
- Switch Function
- On-Mom
- Body Length Or Diameter
- 77.22mm
- Kurşunsuz Kodu
- yes
- Voltage Rated Dc
- 125V
- Pretravel
- 0.015 (0.4mm)
- Parça Durumu
- Active
- Max Voltage Rating Dc
- 250V
- Orientation
- Straight
- Yayın Yılı
- 2012
- Housing Material
- Zinc
- Terminal
- Conduit
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Voltage Rated Ac
- 125V
- Contact Currentdcmax
- 0.5A
- Seri
- V6
- Operating Position
- 2.953 (75.0mm)
- Reach Svhc
- No SVHC
- Contact Ac Max Rating R Load
- 15A@480VAC
- Çalışma Sıcaklığı
- -32°C~71°C
- Body Breadth
- 25.4 mm
- Differential Travel
- 0.002 (0.05mm)
- Actuator Type
- Roller Plunger
- Ingress Protection
- IP40
