Specifications
- Contact Currentdcmax
- 0.5A
- Circuit
- SPDT
- Max Current Rating
- 15A
- Akım Değeri
- 15A
- Depth
- 17.45mm
- Pretravel
- 0.012 (0.3mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Material
- Plastic
- Operating Position
- 0.625 (15.9mm)
- Mechanical Life
- 20,000,000 Cycles
- Switch Function
- On-On
- Pretravelmax
- 0.3 mm
- Yayın Yılı
- 2001
- Actuator Type
- Round (Pin Plunger)
- Overtravel
- 0.005 (0.13mm)
- HTS Kodu
- 8536.50.70.00
- Weight
- 3.401kg
- Reach Svhc
- Unknown
- Max Voltage Rating Ac
- 480V
- Fabrika Tedarik Süresi
- 9 Weeks
- Operating Force
- 198 ~ 255gf
- Max Voltage Rating Dc
- 250V
- Seri
- BZ
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 49.28mm
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Terminal
- Solder
- JESD-609 Kodu
- e3
- Housing Material
- Phenolic
- Contact Materials
- Silver
- Montaj Tipi
- Chassis Mount
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Contact Current Rating
- 15A
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Voltage Rated Ac
- 125V
- Actuator Travel
- 0.43 mm
- Voltage Rated Dc
- 125V
- ECCN Kodu
- EAR99
