Specifications
- Pretravel
- 0.094 (2.4mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Actuator Length
- 267mm
- Material
- Plastic
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Voltage Rated Ac
- 125V
- Mechanical Life
- 20,000,000 Cycles
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Contact Current Rating
- 15A
- Operating Position
- 1.188 (30.2mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Actuator Material
- Stainless Steel
- Max Current Rating
- 16A
- Uzunluk
- 49.28mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Circuit
- SPDT
- Terminal
- Screw
- Orientation
- Straight
- RoHS Durumu
- RoHS Compliant
- Depth
- 17.45mm
- Contact Materials
- Silver
- Akım Değeri
- 15A
- Housing Material
- Phenolic
- Overtravel
- 0.094 (2.4mm)
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 10 Weeks
- Differential Travel
- 0.006 (0.15mm)
- Max Voltage Rating Ac
- 480V
- Reach Svhc
- Unknown
- Parça Durumu
- Active
- Weight
- 3.401kg
- Çalışma Sıcaklığı
- -55°C~85°C
- Release Force
- 7.087gf
- Operating Force
- 56gf
- Body Height
- 26.67mm
- Seri
- BZ
- Pretravelmax
- 2.39 mm
- Voltage Rated Dc
- 250V
