Specifications
- Pretravel
- 0.012 (0.3mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Material
- Plastic
- Switch Function
- On-On
- Mechanical Life
- 20,000,000 Cycles
- Operating Position
- 0.922 (23.4mm)
- Contact Currentdcmax
- 0.5A
- Max Current Rating
- 15A
- Circuit
- SPDT
- Onay Kuruluşu
- CE, CSA, UL
- Depth
- 17.5mm
- Akım Değeri
- 15A
- Overtravel
- 0.219 (5.6mm)
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 9 Weeks
- Weight
- 3.401kg
- Operating Force
- 170 ~ 269gf
- Seri
- BZ
- Contact Voltageacmax
- 480V
- Pretravelmax
- 0.3 mm
- Yayın Yılı
- 1999
- Actuator Type
- Overtravel Plunger
- Montaj Tipi
- Panel Mount
- Voltage Rated Ac
- 125V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Ambalaj
- Bulk
- Kurşunsuz Kodu
- yes
- Actuator Material
- Steel
- Uzunluk
- 49.3mm
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Terminal
- Solder
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Contact Materials
- Gold
- Housing Material
- Phenolic
- JESD-609 Kodu
- e3
- Electricallife
- 100000 cycles
- Terminal Kaplaması
- Matte Tin (Sn)
- Özellikler
- Reset Plunger on Bottom
- Parça Durumu
- Active
