Specifications
- Pretravelmax
- 0.3 mm
- Actuator Travel
- 0.43 mm
- Yayın Yılı
- 2001
- Voltage Rated Dc
- 250V
- Actuator Type
- Round (Pin Plunger)
- ECCN Kodu
- EAR99
- Montaj
- Chassis Mount, Panel, Screw
- Current Rating Amps
- 15A AC
- Terminal Stili
- Screw Terminal
- HTS Kodu
- 8536.50.70.00
- Overtravel
- 0.005 (0.13mm)
- Çalışma Sıcaklığı
- -55°C~85°C
- Release Force
- 113gf
- Weight
- 3.401kg
- Parça Durumu
- Active
- Differential Travel
- 0.0006 (0.015mm)
- Max Voltage Rating Ac
- 480V
- Terminal Kaplaması
- Matte Tin (Sn)
- Fabrika Tedarik Süresi
- 10 Weeks
- Operating Force
- 198 ~ 283gf
- Seri
- BZ
- Body Height
- 21.59mm
- Circuit
- SPDT
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Uzunluk
- 49.28mm
- Max Current Rating
- 15A
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Terminal
- Screw
- JESD-609 Kodu
- e3
- Housing Material
- Phenolic
- Akım Değeri
- 15A
- Contact Materials
- Silver
- Depth
- 17.45mm
- Pretravel
- 0.012 (0.3mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Material
- Plastic
- Montaj Tipi
- Chassis Mount
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Position
- 0.625 (15.9mm)
