Volume pricing
- 1+ pcs$6.99
- 10+ pcs$6.60
- 100+ pcs$6.22
- 500+ pcs$5.87
Shipping
Same-day dispatch from stock
Genuine parts
Verified sourcing
RoHS
Compliant
Support
Technical team support
Specifications
- Operating Force
- 255gf
- Body Height
- 21.34mm
- Seri
- BZ
- Overtravel
- 0.005 (0.13mm)
- HTS Kodu
- 8536.50.70.00
- Fabrika Tedarik Süresi
- 12 Weeks
- Differential Travel
- 0.0007 (0.018mm)
- Max Voltage Rating Ac
- 480V
- Terminal Kaplaması
- Matte Tin (Sn)
- Parça Durumu
- Active
- Weight
- 3.401kg
- Çalışma Sıcaklığı
- -55°C~85°C
- Release Force
- 113gf
- Current Rating Amps
- 15A AC
- Montaj
- Chassis Mount, Panel, Screw
- ECCN Kodu
- EAR99
- Actuator Type
- Round (Pin Plunger)
- Terminal Stili
- Solder Lug
- Actuator Travel
- 0.43 mm
- Pretravelmax
- 0.3 mm
- Yayın Yılı
- 2001
- Material
- Plastic
- Montaj Tipi
- Chassis Mount
- Switch Function
- On-Mom
- Mechanical Life
- 20,000,000 Cycles
- Voltage Rated Ac
- 125V
- Kurşunsuz Kodu
- yes
- Ambalaj
- Bulk
- Contact Current Rating
- 15A
- Operating Position
- 0.625 (15.9mm)
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Pretravel
- 0.012 (0.3mm)
- Contact Ac Max Rating R Load
- 15A@480VAC
- Terminal
- Solder
- RoHS Durumu
- RoHS Compliant
- Orientation
- Straight
- Depth
- 17.45mm
- Contact Materials
- Silver
- Akım Değeri
- 15A
- Housing Material
- Phenolic
