Specifications
- Switch Function
- On-Mom
- Yayın Yılı
- 2001
- Contact Ac Max Rating R Load
- 15A@480VAC
- Seri
- LN
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Fabrika Tedarik Süresi
- 4 Weeks
- Pretravelmax
- 0.76 mm
- Voltage Rated Dc
- 125V
- Çalışma Sıcaklığı
- -32°C~55°C
- Depth
- 42.42mm
- Max Voltage Rating Dc
- 250V
- Housing Material
- Zinc
- Operating Force
- 2268gf
- HTS Kodu
- 8536.50.70.00
- Body Height
- 82.55mm
- Current Rating Amps
- 15A AC 500mA DC
- Akım Değeri
- 15A
- Differential Travel
- 0.004 (0.1mm)
- ECCN Kodu
- EAR99
- Actuator Type
- Round (Pin Plunger)
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Kurşunsuz Kodu
- yes
- Voltage Rated Ac
- 125V
- Ambalaj
- Bulk
- Contact Dc Max Rating R Load
- .5A@125VDC
- Montaj Tipi
- Chassis Mount
- Max Current Rating
- 15A
- Contact Currentdcmax
- 0.5A
- Genişlik
- 25.4mm
- Pretravel
- 0.030 (0.8mm)
- Orientation
- Straight
- Actuator Travel
- 5.92 mm
- Terminal Stili
- Wire Leads
- Parça Durumu
- Obsolete
- Terminal
- Conduit
- Circuit
- SPDT
- Contact Voltageacmax
- 480V
- Operating Position
- 1.640 (41.65mm)
- Montaj
- Chassis Mount, Screw
- Özellikler
- Actuator Mounted Left Side
