Specifications
- Circuit
- SPDT
- Terminal
- Conduit
- Parça Durumu
- Obsolete
- Overtravel
- 0.203 (5.15mm)
- RoHS Durumu
- RoHS Compliant
- Uzunluk
- 103.12mm
- Release Force
- 454gf
- Özellikler
- Actuator Mounted Right Side
- Montaj
- Chassis Mount, Screw
- Operating Position
- 1.640 (41.65mm)
- Contact Voltageacmax
- 480V
- Pretravel
- 0.025 (0.65mm)
- Genişlik
- 42.418mm
- Contact Currentdcmax
- 0.5A
- Max Current Rating
- 15A
- Montaj Tipi
- Chassis Mount
- Ambalaj
- Bulk
- Terminal Stili
- Wire Leads
- Actuator Travel
- 5.795 mm
- Orientation
- Straight
- Akım Değeri
- 15A
- Current Rating Amps
- 15A AC 500mA DC
- Body Height
- 90.42mm
- HTS Kodu
- 8536.50.70.00
- Operating Force
- 227 ~ 283gf
- Housing Material
- Zinc
- Max Voltage Rating Dc
- 250V
- Voltage Rated Ac
- 125V
- Kurşunsuz Kodu
- yes
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Actuator Type
- Round (Pin Plunger)
- ECCN Kodu
- EAR99
- Differential Travel
- 0.003 (0.075mm)
- Pretravelmax
- 0.635 mm
- Fabrika Tedarik Süresi
- 4 Weeks
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Seri
- LN
- Contact Ac Max Rating R Load
- 15A@480VAC
- Yayın Yılı
- 2001
- Switch Function
- On-Mom
