Specifications
- Current Rating Amps
- 15A AC 500mA DC
- Voltage Rated Ac
- 480V
- Max Voltage Rating Dc
- 250V
- Switch Type
- SNAP ACTING/LIMIT SWITCH
- Operating Position
- 2.015 (51.2mm)
- Depth
- 77.2mm
- RoHS Durumu
- RoHS Compliant
- Pretravelmax
- 0.3 mm
- Özellikler
- Reset Plunger on Bottom
- Yayın Yılı
- 2005
- Operating Force
- 170 ~ 269gf
- Terminal Stili
- Screw Terminal
- Pozisyon Sayısı
- 2
- Terminal
- Conduit
- Ingress Protection
- IP40
- Circuit
- SPDT
- Çalışma Sıcaklığı
- -32°C~71°C
- Uzunluk
- 25.4mm
- ECCN Kodu
- EAR99
- Montaj
- Chassis Mount, Screw
- HTS Kodu
- 8536.50.70.00
- Kılıf / Paket
- 125
- Voltage Rated Dc
- 125V
- Pretravel
- 0.012 (0.3mm)
- Contact Currentdcmax
- 0.5A
- Overtravel
- 0.141 (3.6mm)
- Kurşunsuz Kodu
- yes
- Actuator Travel
- 3.86 mm
- Seri
- E6
- Nem Hassasiyeti (MSL)
- 1 (Unlimited)
- Number Of Poles
- 1
- Onay Kuruluşu
- CSA, UL
- Max Current Rating
- 500mA
- Fabrika Tedarik Süresi
- 20 Weeks
- Body Height
- 65.88mm
- Actuator Type
- Roller Plunger
- Ambalaj
- Bulk
- Montaj Tipi
- Chassis Mount
- Housing Material
- Zinc
- Akım Değeri
- 15A
